RF POWER AMPLIFIER - C BAND
DRIVER AMPLIFIER
- +28.5 dBm output.
- 5 GHz to 6 GHz band
- Return Loss 18 dB
HYBRID PCB FOR RF AMPLIFIER
HYBRID PCBA
- Design and development of Hybrid PCBA for RF amplifiers.
- Board design will be done as per customer's specs.
- RF board and FR 4 boards sandwiched as single PCB
- Power sequencing realization on FR4
- RF amplifier realization on Rogers
- Advantages of this design: Space minimization, improve signal integrity.
RF POWER AMPLIFIER- S BAND
10 WATTS AMPLIFIER
- GaN module based design.
- S band
- Return Loss 18 dB
RF POWER SPLITTERS - L BAND
M.No: STPL-SPT-1000
- We do custom design splitters
- Model STPL-SPT-1000 covers: 850 MHz to 1200 MHz
- Insertion Loss : 0.3 dB
- Return Loss : 18 dB
- Isolation : 40 dB at 1 GHz
RF POWER SPLITTERS - S BAND
M.No: STPL-SPT-2500
- We do custom design splitters
- Model STPL-SPT-2500 covers 2.2 GHz to 2.8 GHz
- Insertion Loss : 0.3 dB
- Return Loss : 18 dB
- Isolation 25 dB at 2.5 GHz
LOW NOISE AMPLIFIER- L BAND
LOW NOISE AMPLIFIER (STPL-LNA-6G1)
- Wide band - 500 MHz to 2 GHz.
- Gain: 19.5 dB
- Noise Figure - < 0.65 dB at 1900 MHz
- Gain: 16.5 dBm at 1900 MHz
- Applications: TDD or FDD systems, General purpose wireless, Repeaters
- Power Down Mode
FPGA BOARD
EVALUATION BOARD
- Designed FPGA board with ALTERA MAX 10M08 Chipset.
- Suitable for quick experimentations with multiple Interfaces.
- We provide Training on FPGA software development
- Multiple use cases can be developed with this board.
- Applications - Secured Transceivers with custom modulations.
SMART CONTROL SOLUTIONS
SMART CONTROLS
- Automatic Motor Control and Monitoring.
- For Agri Applications
- Cloud Controlled
- Single motor management
